ABS Premier Pharmacy Freestanding Undercounter Refrigerators feature a microprocessor temperature controller and display, which allow for precise temperature control, verification and recovery versus mechanical style thermostats.
The Built-In models are designed with a front-breathing ventilation system, eliminating the need for clearance around the top and sides of the unit, and enabling the user to incorporate these units into cabinets and other applications where free space is limited.
The acceptable temperature ranges for vaccine storage are 36°F to 46°F (or 2°C and 8°C) in the refrigerator and -58°F and 5°F (or -50°C and -15°C) in freezers.
Environmentally friendly, natural hydrocarbon (HC) refrigerants (not containing hydrofluorocarbons) vastly reduce global-warming potential (GWP) while meeting new EPA/SNAP mandates and UL, ASHRAE compliance guidelines.
Operation
- Adjustable operating temperature range from -20°C to -30°C
- Factory preset at -30°C
- Microprocessor temperature controller
- Manual defrost
- Digital temperature display
- Remote alarm contacts
- Audible and visual high and low temperature alarms
- 2 probes; 1 in air and 1 in sample bottle
- Probe access port (3/8")
- Pyxis®, Omnicell® and AcuDose RX® compatible
- 115V, 60 Hz, 2.2 Amps, 1/4 HP UL/C-UL listed
- HFC-free refrigerant (R290), foam insulation and packaging
Interior
- Three adjustable shelves with guard rail on back to prevent product from being pushed against the back wall
- Bottom footed shelf to allow air circulation
- Back wall evaporator cover
- LED interior light
Exterior
- White cabinet and door
- High density urethane foam cabinet and door insulation
- One solid swing door, right hinged, not reversible
- Keyed door lock
- Magnetic door gasket for positive seal
- Recessed door handle
- Levelling legs
- Exterior dimensions: 23 3/4" W x 24"D x 32 1/8"H
- 4 cu. ft. capacity
- Shipping weight: 128 lbs.
Warranty
- Two year parts and labour warranty, plus an additional three year compressor parts only warranty
Note: This unit must have 4” clearance on sides and back for adequate ventilation.
View the diagram
